Maximum performance, minimum volume.

Raijintek’s latest release the ZOFOS EVO is a case which has been designed to be practical; featuring the latest sound insulation, magnetic covers and the option for either a fully enclosed or windowed case. This full tower case supports up to EE-ATX motherboards, 470mm GPUs and up to three 360mm radiators for a comprehensive gaming system.

ZOFOS Evo – At a glance

– Syncronizable RGB Front Panel Design

– Support for up to an EE-ATX motherboard

– I/O Panel with 2 x USB 3.0 and 1 x USB C-Type

– Support up to 10 x 3.5”HDD + 3 x 2.5”HDD

– Fits graphics cards up to 470 mm long

– Space for up to a 420 mm radiator, with two additional 360mm


ZOFOS Evo – Silent Version



The ZOFOS Evo silent edition is fitted with the latest high density sound insulation pads, made from eco-friendly cotton, secured with magnetic front and top panels. It comes pre-installed with 2 x 120mm front fans as well as an additional 120mm rear fan. The RGB control board allows for RGB sycronization with the motherboard, with optional remote control included.

Thanks to its magnetic brackets, the front is also easy to remove, behind this lies a honeycomb-style mesh with dust filter and two  5.25″ optical drive bays.

ZOFOS Evo – Window Edition

The ZOFOS Evo is also avaliable with a 4mm tempered glass side panel, exchanging the high density sound insulation padding for a visual update. The Window Edition also comes with a pre-installed 120mm RGB rear fan, RGB synchronized controller and remote.

Thanks to its magnetic brackets, the front is also easy to remove, behind this lies a honeycomb-style mesh with dust filter and two  5.25″ optical drive bays.
Comprehensive Cooling Solutions

Behind the front panel, users can install up to three 120 mm or 140 mm fans. Optionally, a radiator up to 420 mm in size can be installed, which combined with the fans can be up to 85 mm deep. The cages are attached with knurled screws and can be easily removed if necessary to make room for graphics cards up to 470mm long.

The top of the case offers space for two 140 mm- or three 120 mm fans or even a radiator up to 360 mm in size. An additional 360 mm radiator with a depth of 85 mm can be placed vertically at the front of the right Panel. There is also a mesh grid. CPU coolers used in the Zofos Evo Silent can be up to 190 mm high

Top Radiator – 240/280/360mm radiator (85mm Clearance)

Top Fan          – 3 x 120mm or 2 x 140mm fans



Front Radiator – 240/280/360/420mm radiator (85mm clearance)

Front Fan          – 3 X 120mm or 3 x 140mm
Side Radiator    – 240/360mm radiator (85mm clearance)

Rear Fans           – 1 x 120mm or 1 x 140mm

Technical Specifications

Available color & internal color              Black & Matt Black

Material                                                     SPCC 1.0mm + ABS

Dimension chassis body (D/W/H)           617*245*598mm

M/B Type                                                    EE-ATX / E-ATX / ATX/ MICRO ATX/MINI ITX

Graphic Card Support & Space              YES, 470mm

Power Supply                                            PS-2, Internal Bottom PSU

5.25” Device                                              2

3.5” Device                                                10 ( or 2.5″*10)

2.5″ Device (option/removable)               3

I/O Panel                                                     USB3.0*2, C-Type*1(slient version only), HD Audio

PCI Slot                                                       10

CPU Cooler space                                      190mm

HDD Tool-free                                              YES

PCI Slot Tool-free                                        YES

Side Panel                                                    High-Density Sound insulation pad

Front Cooling                                              120mm*2;120mm*3  fan ; 140mm*2 ; 140mm*3

or 240/280/360/420 mm radiator (85mm thickness)

Rear Cooling Fan                                        120/140mm*1

Top Cooling                                                 Fan 120mm*2 / 140mm*2 / 120mm*3

or 240/280/360mm radiator (85mm thickness)

Additional accessories                              MB bracket – 240/360 mm radiator (85mm thickness),

RGB Remote Controller*1 & control board*
